Pile Driven Fixed Tilt Systems

MaxSpan™

Best Quality & Priced Fixed Tilt Systems for Most Solar Modules
gamechange solar

Pile Driven Fixed Tilt Systems

MaxSpan™

Optimal System for Sloping Ground & Extreme Weather Condition
gamechange solar

Leader in the Industry

gamechange solar

Innovations

gamechange solar

  • Industry’s longest spans and fewest foundations: as few as 190 per MW for 2 up portrait and 130 per MW for 3 up portrait
  • Articulating purlin connections to navigate up to 15% terrain slopes
  • Supports all poly, glass and thin film modules in portrait or landscape
  • Rugged design enables 175 mph [78.23 m/s] wind and 90 psf [4.31 kPa] snow loads
  • Turnkey install, pull test and geotech services available
  • 20 men install 1.55MW per week

Technical Datasheet Time Study
gamechange solar

Superior Terrain Navigation Adjustability

Articulating purlins between tables enable installation on sites with complex slope issues, which when combined with post and post bracket adjustment handle up to 15% east-west terrain slopes and undulations
gamechange solar
gamechange solar
gamechange solar
gamechange solar
gamechange solar
Articulating purlin connections combine with slots or post brackets to navigate up to 15% terrain slopes
Patent pending articulating purlin connection to navigate sloping terrain
gamechange solar
Purlins for all MaxSpan™ systems have multiple mounting holes allowing 6"[15.24cm] east-west adjustability
gamechange solar
gamechange solar
Nesting components eliminate brackets,
have long slots enabling 3 axes of adjustability.
gamechange solar
MaxSpan™ FastBuild
Industry’s Lowest Part Count of all Pile Systems

  • Industry’s fastest install system due to minimal parts
  • Lowest A frame part count of any system, just 3 parts (pile, beam and brace) and 6 bolts for 2 up
  • Three axes of adjustability demanded by installers for navigating real world site conditions where significant adjustability in the field is required
  • The unmatched span capability of the MaxSpan™ means there are fewer foundations than competing systems, which also means less piles and less pile installation cost. As few as 190 piles per MW
  • Standard system has 3.5"[8.89cm] vertical adjustability
  • Optional post extenders allow 10" [25.4cm] vertical adjustability
  • Typical Part Count Comparison vs. Competitors for A Frames (Post, Brace, Beam and Related Brackets)

    gamechange solar
gamechange solar

Long slots allow 3.5"[8.89cm] vertical adjustability


Click to see the movement
gamechange solar
gamechange solar



gamechange solar

Optional post extenders allow 10"[25.4cm] vertical adjustability


Click to see the movement
gamechange solar
gamechange solar




Telescoping post bracket with up to 5"[12.7cm] vertical adjustment for fast top of pile leveling
gamechange solar
gamechange solar



MaxSpan™ WideFlange
Optimal System for WideFlange

  • Industry’s most flexible racking system handles undulating ground conditions
  •
  • Telescoping post bracket with up to 5"[12.7cm] vertical adjustment for fast top of pile leveling
Undulating Ground Conditions
gamechange solar

MaxSpan™ Thin Film Post System

  • Supports all thin film panels for all vendors
  • Thin film panel clamps mount using rivets, T bolts or socket bolts
  • I beam available as alternate foundation
  • 60% fewer foundations than other First Solar® racking enables faster install (typically 300 piles per MW vs over 500 piles per MW for other vendors)
Shown left: MaxSpan™ thin film with First Solar Series 4 Panels 6up in landscape
Note. First Solar is a registered trademark of First Solar, Inc.

gamechange solar

FEATURES

  • Supports all double-sided glass thin film & other modules
  • Up to 4 ft.[121.92cm] ground clearance eliminates snow & vegetation shading issues
  • Galvanized Z purlins have integrated trays for easy wire management
  • 5 to 35° tilt with multiple inter-row spacing options
  • Stamped layout & engineering analysis for every project
  • Integrated grounding with star washers or teethed module clamps included - approved under ETL /UL 2703

gamechange solar

Self Hanging Purlin Supports Reduce Purlin Labor 40%

  • Reduce labor for purlin mounting by 40% because two men can place purlins on supports and then one man can bolt them on versus five man team previously
  • Available Q4 2017
gamechange solar

3 Up Portrait Option Available

  • Typically 5% or more lower system cost
  • Wider row spacing
  • Reduces number of foundations per MW up to 30%
gamechange solar

QuikClamp™ Speeds Install 30% for First Solar Series 4 Modules

  • QuikClamp™ may be bolted on by either driving serrated flange nut from below with SelfLock™ feature using hex bolts or from above with button head bolts.
  • QuikClamp™ bottom: First Solar approved Santoprene™ TPV, QuikClamp™ Top: G90 Steel
gamechange solar

First Solar Series 4™ Mounting Rails

  • The GameChange MaxSpan™ offers a mounting solution for the high performing and efficient First Solar Series 4™ module. Three First Solar Series 4™ modules are held on top of each pair of purlins in landscape configuration.
  • The GameChange MaxSpan™ First Solar module configuration helps improve energy production by increasing the module density on each table.
Overview Sheet
gamechange solar

Solar Frontier Mounting Rails

  • The GameChange MaxSpan™ offers a mounting solution for the high performing and efficient Solar Frontier CIS module. Two Solar Frontier CIS modules are held in between each pair of purlins in portrait configuration.
  • The GameChange MaxSpan™ CIS module configuration helps improve energy production by increasing the module density compared to the competition.
Overview Sheet
gamechange solar




Helical Post System - Single Post

  • Optimal for peat bogs and other very soft soils or areas with frost jacking concerns
  • Dual post also available

MAXSPAN™ TRADE SHOW VIDEO

ballasted-solar-farm
gamechange solar

TEST & CERTIFICATION

  • Wind tunnel tested by industry leader CPP
  • Meets IBC and ASME standards for structural loading
  • ETL / UL 467 GameChange top mount clamps or star washers included
  • ETL / UL 2703 tested
  • Independent assessment by Black & Veatch
  • Warranty 20 years
  • First solar Module Clamps: G90 Steel or AL

PULL TEST, GEOTECH & INSTALLATION SERVICES

  • Free pull test on orders over 5 MW
  • Turnkey installation of piles, racks and modules available
  • Vertical and lateral resistance of the post is determined by pull test
  • Pull test data is analyzed by our in-house engineering team in parallel with geotechnical report to give the best and most accurate information for embedment depth and post type

gamechange solar




“At HBC quality and install speed are critical to the success of our business. GameChange has been able to deliver a solid product on time and installation has been simple and efficient. ”

Jack Horne
Horne Brothers, Nationwide Installation Leader
Over 500MW Installed in 2015

“GameChange's Innovative (Post-Driven) solution offered a quality product at the best value in the market.”

Chris Bullinger
CEO, Hecate Energy LLC

Any Questions ? Don't Hesitate to Ask.

MaxSpan™ System : Minimum order size 3 MW
